OPEN FRYERS
F5 Series
Introducing Henny Penny’s game-changer: the F5 open fryer – Say goodbye to boring fryers and hello to a whole new world of savings and efficiency.
Witness the F5 revolution: a beacon of resource optimization, effortlessly saving on oil, labor, and maintenance costs. This isn’t just a fryer; it’s a financial wizard that positively impacts your operation’s bottom line day in and day out.
- ZTouch-screen control panels with product images
- ZFastest open-fryer filtration cycle in the industry
- ZBuilt-in troubleshooting prompts and help guides....easy for training.
- Z30 lbs of oil per vat & ATO (automatic top-off) system
F5 Series
Unlike Any Fryer You’ve
Ever Used Before
The Henny Penny F5 open fryer is designed from the ground up to make frying high-quality food easier, safer and more efficient for any kitchen. The F5 is built on our reliable 30 lb oil-saving platform but offers a whole new interface that makes everything about this advanced fryer simple. The control consists of a 7-inch touch and swipe screen with a graphics-based operating system that is so intuitive it can reduce initial training by up to 50%.* Built-in Simple Touch Filtration lets crew filter individual vats as needed while continuing to cook in other vats uninterrupted. Just touch the screen three times (or less) to begin filtering. The system drains and filters oil, rinses away crumbs and returns hot filtered oil to the vat in three minutes!
LEARN MORE
Features + Benefits
- Z40% less oil, same throughput as 50 lb vat
- ZSaw the Evolution Elite and said "I can do that, but better"
- ZIntuitive touch-and-swipe interface
- ZFights crime and busy dinner rushes
- ZEasy training for staff and new employees
- ZBuilt-in troubleshooting prompts and help guides
- ZEarns ENERGY STAR® mark
- ZEasier serviceability means technicians are in and out. Less downtime.
- ZMajority of basic functions are icon- or picture-based
- ZSleek, thoughtful design features smooth lines and flat surfaces.....would easily win GQ's fryer of the year (if they did that).
- ZFastest filtration cycle on BOTH sides of the Mississippi River
SPECIFICATIONS
Technical Details
AVAILABLE MODELS
OFE 511 1-well electric
OFE 512 2-well electric
OFE 513 3-well electric
OFE 514 4-well electric
product dimensions
OFE 511
Dimensions
Width 16.63 in (422 mm)
Depth 36.90 in (938 mm)
Height 46.58 in (1184 mm)
Crated
Length 33 in (838 mm)
Depth 21 in (533 mm)
Height 52 in (1321 mm)
Volume 21 ft3 (0.59 m3 )
Weight
1 full N/A
1 split N/A
2 full N/A
2 split N/A
3 full N/A
3 split N/A
4 full N/A
4 split N/A
OFE 512
Dimensions
Width 31.10 in (790 mm)
Depth 32.94 in (837 mm)
Height 46.58 in (1184 mm)
Crated
Length 36 in (914 mm)
Depth 36 in (914 mm)
Height 55 in (1397 mm)
Volume 41 ft3 (1.2 m3 )
Weight
1 full N/A
1 split N/A
2 full N/A
2 split N/A
3 full N/A
3 split N/A
4 full N/A
4 split N/A
OFE 513
Dimensions
Width 46.70 in (1186 mm)
Depth 32.94 in (837 mm)
Height 46.58 in (1184 mm)
Crated
Length 51 in (1295 mm)
Depth 36 in (914 mm)
Height 55 in (1397 mm)
Volume 57 ft3 (1.6 m3 )
Weight
1 full N/A
1 split N/A
2 full N/A
2 split N/A
3 full N/A
3 split N/A
4 full N/A
4 split N/A
OFE 514
Dimensions
Width 62.20 in (1580 mm)
Depth 32.94 in (837 mm)
Height 46.58 in (1184 mm)
Crated
Length 67 in (1702 mm)
Depth 36 in (914 mm)
Height 55 in (1397 mm)
Volume 77 ft3 (2.2 m3 )
Weight
1 full N/A
1 split N/A
2 fullN /A
2 split N/A
3 full N/A
3 split N/A
4 full N/A
4 split N/A
Oil Capacity
30 lb or 15 L per full vat
Electrical Data
| Volts | Phase | Hertz | kW per well* | 14 kW Amps per well | 17 kW Amps per well | Wire***/td> |
| 208 | 3 | 60 | 14.0 | 39.4** | 48** | 3+G |
| 220/240 | 3 | 50/60 | 14.0 | 36 | 44.6** | 3+G |
| 240 | 3 | 60 | 14.0 | 34.2** | 41.6** | 3+G |
| 220/380 | 3 | 50/60 | 14.0 | 24.3 | 30.2** | 3NG |
| 230/410 | 3 | 50/60 | 14.0 | 24.3 | 30.2** | 3NG |
| 240/415 | 3 | 50/60 | 14.0 | 24.3 | 30.2** | 3NG |
Heating Data
OFE 511
Heating immersed elements
Low 14.0 kW total
High* 17.0 kW total
OFE 512
Heating immersed elements
Low 28.0 kW total
High* 34.0 kW total
OFE 513
Heating immersed elements
Low 42.0 kW total
High* 51.0 kW total
OFE 514
Heating immersed elements
Low 56.0 kW total
High* 68.0 kW total
*17.0 kW power available with full vat units, only. **Additional amperage required to operate non-heating electrical components
Accessories With Unit
Accessories shipped with unit
Fry baskets (additional charge)
- 1 full basket per well
- 2 half baskets per well
1 basket support for each vat
Element lift tool
Installation and operating manual
Optional Accessories
FDS 210 fryer dump station with matching profile—can be attached
ODS 315 50 lb oil disposal shuttle
Fry well covers
SmartFilter™ pads
SmartFilter™ paper
Oil dispensing jug
Required Clearances
Required clearances
Sides 2 in (51 mm) from combustible materials or other heat producing equipment; otherwise no clearance required
Back 6 in (152 mm) air flow, connections
Front 30 in (762 mm) remove drain pan
Top No clearance required
